42 43
English
ATX Power Connector
(24-pin ATXPWR1)
3V
3V
GND
GND
5V
5V
GND
PWROK_PS
5VSB
12V
12V
3V
121
13
24
3V
-12V
GND
PSON#
GND
GND
GND
5V
5V
5V
GND
N/A
is motherboard provides a
24-pin ATX power connector.
To use a 20-pin ATX power
supply, please plug it along Pin
1 and Pin 13.
ATX 12V Power
Connectors
(8-pin ATX12V1)
(4-pin ATX12V2)
4
8
1
5
12V
GND
1
2
3
4
GND
is motherboard provides
one 8-pin and one 4-pin ATX
12V power connectors.
SATA DOM Power
Connector
(3-pin SATAPWR1)
(3-pin SATAPWR2)
GND
+5V
+12V
Please use a SATA power cable
to connect this SATA Power
Connector and your SATA
HDD for supplying power
from the motherboard, when
using DC-IN mode without
SATA power supply.
TPM Header
(17-pin TPM1)
1
GN
D
SMB_DATA_MAIN
LAD2
LAD1
GND
S_PWRDWN#
SERIRQ#
GN
D
PCICL
K
PCIRST#
LAD3
+3V
LAD0
+3VSB
GND
LFRAME#
SMB_CLK_MAIN
is connector supports
Trusted Platform Module
(TPM) system, which can
securely store keys, digital
certicates, passwords, and
data. A TPM system also helps
enhance network security,
protects digital identities, and
ensures platform integrity.
