ASROCK 970DE3/U3S3 Quick Installation Guide

106
ASRock 970DE3/U3S3 Motherboard
1.2 Özellikler
Platform - ATX Form Faktörü: 12,0-inç x 7,5-inç, 30,5 cm x 19,1 cm
- Tüm Katı Kapasitör tasarımı
CPU - Soket AM3+ işlemcileri desteği
- Soket AM3 işlemcileri desteği: AMD Phenom
TM
II X6 / X4 / X3 /
X2 (920 / 940 hariç) / Athlon II X4 / X3 / X2 / Sempron
işlemcileri
- Sekiz Çekirdekli CPU Desteği
- Digi Güç Tasarımı
- 140W’ye kadar CPU’yu destekler
- ACC цzellikli (Geliюmiю Saat Kalibrasyonu) AMD
OverDrive
TM
’э destekler
- AMD’nin Cool ‘n’ Quiet
TM
Teknolojisini Destekler
- FSB 2600 MHz (5,2 GT/sn)
- Untied Overclocking Teknolojisini destekler (bkz. DİKKAT 1)
- Hyper-Transport 3.0 (HT 3.0) Teknolojisini Destekler
Yonga seti - Kuzey Köprüsü: AMD 770
- Güney Köprüsü: AMD SB710
Bellek - Çift Kanallı DDR3 Belleği Teknolojisi (bkz. DİKKAT 2)
- 4 x DDR3 DIMM yuva
- DDR3 1866(OC)/1600(OC)/1333/1066/800 ECC olmayan, ara
belleksiz bellek (bkz. DİKKAT 3)
- Sistem belleğinin maks. kapasitesi: 32 GB (bkz. DİKKAT 4)
Genişletme - 1 x PCI Express 2.0 x16 yuva (PCIE3: x16 modu)
Yuvası - 3 x PCI Express 2.0 x1 yuva
- 2 x PCI yuva
Ses - 5,1 Kanal HD Ses (Realtek ALC662 Ses Kodeki)
- THX TruStudio
TM
destekler
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/sn
- Realtek RTL8111E
- LAN’da Uyan özelliğini destekler
- LAN Kablo Algılama’yı destekler
- Enerji Verimli Ethernet 802.3az desteği
- PXE destekler
Arka Panel G/З Paneli
- 1 x PS/2 Fare Portu
- 1 x PS/2 Klavye Portu
- 1 x Seri Portu: COM1
- 4 x Kullanıma Hazır USB 2.0 Portu
- 2 x Kullanıma Hazır USB 3.0 Portu
Türkçe

ASROCK 970DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
I/O ports	1 x IR 1 x ATA133 IDE 1 x HDMI_SPDIF 1 x Power LED 1 x 8 pin 12V power
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	FCC, CE, WHQL ErP/EuP Ready
Component for	PC
Motherboard chipset	AMD 770
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP Media Center / XP 64-bit
Supported storage drive interfaces	SATA
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	191 mm
Width	305 mm
