ASRock 970DE3/U3S3 Motherboard
1.2 Spesifikasi
Podium - Faktor Form ATX: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm
- Desain All Solid Capacitor
CPU - Stopkontak AM3+
- Stopkontak AM3 untuk AMD Phenom
TM
II X6 / X4 / X3 / X2
(kecuali 920 / 940) / Athlon II X4 / X3 / X2 / Sempron
processor
- Dukungan CPUT Delapan Inti
- Digi Power Desain
- Mendukung CPU hingga 140 W
- Mendukung AMD OverDrive
TM
dengan fi tur ACC (Advanced
Clock Calibration [Kalibrasi Clock Lanjutan])
- Dapat digunakan AM’s Cool ‘n’ Quiet
TM
Technology
- FSB 2600 MHz (5.2 GT/s)
- Menggunakan Teknologi Untied Overclocking
- Dapat digunakan Hyper-Transport 3.0 (HT 3.0) Technology
Grup Chip - Jembatanutara: AMD 770
- Jembatanselatan: AMD SB710
Ingatan - Teknologi ingatan DDR3 dwisaluran
- 4 x Alur DDR3 DIMM
- Menggunakan DDR3 1866(OC)/1600(OC)/1333/1066/800
- Kapasitas paling banyak: 32GB
Alur Ekspansi - 1 x PCI Express 2.0 x16 slot (PCIE3: mode x16)
- 3 x PCI Express 2.0 x1 slot
- 2 x Alur PCI
Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
- Menggunakan THX TruStudio
TM
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Menggunakan Wake-On-LAN
- Mendukung Deteksi Kabel LAN
- Mendukung Energy Effi cient Ethernet 802.3az
- Mendukung PXE
Bahasa Indonesia

ASROCK 970DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
I/O ports	1 x IR 1 x ATA133 IDE 1 x HDMI_SPDIF 1 x Power LED 1 x 8 pin 12V power
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	FCC, CE, WHQL ErP/EuP Ready
Component for	PC
Motherboard chipset	AMD 770
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP Media Center / XP 64-bit
Supported storage drive interfaces	SATA
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	191 mm
Width	305 mm
