ASROCK A520M-ITX/ac - Page 5

English
2
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 Addressable LED Header (ADDR_LED1)
3 RGB LED Header (RGB_LED1)
4 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6 ATX Power Connector (ATXPWR1)
7 SATA3 Connectors (SATA3_1_3)
8 SATA3 Connectors (SATA3_2_4)
9 USB 3.2 Gen1 Header (USB3_4_5)
10 System Panel Header (PANEL1)
11 USB 2.0 Header (USB_3_4)
12 Clear CMOS Jumper (CLRCMOS1)
13 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
14 Chassis Speaker Header (SPEAKER1)
15 Front Panel Audio Header (HD_AUDIO1)
16 ATX 12V Power Connector (ATX12V1)
