ASROCK A520M-ITX/ac Manual

83
A520M-ITX/ac
Bahasa Indonesia
Spesikasi
Platform
•
Bentuk dan Ukuran Mini-ITX
•
Desain Kapasitor Solid
CPU
•
Mendukung AMD AM4 Ryzen™ Gen 3 / AMD Ryzen™ Prosesor
masa depan (Prosesor Seri 3000 dan 4000)*
* Tidak kompatibel dengan AMD Ryzen™ 5 3400G dan Ryzen™ 3
3200G.
•
Desain Digi Power
•
Desain 8 Fase Daya
Chipset
•
AMD B550
Memori
•
Teknologi Memori DDR4 Dua Saluran
•
2 x Slot DIMM DDR4
•
CPU seri AMD Ryzen (Matisse) yang mendukung memori ECC &
non-ECC, tanpa buering DDR4 4600+(OC)/4533(OC)/
4466(OC)/4400(OC)/4333(OC)/4333(OC)/4266(OC)/4200(OC)/
4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/
3466(OC)/3200/2933/2667/2400/2133*
•
APU seri AMD Ryzen (Renoir) yang mendukung memori ECC &
non-ECC, tanpa buering DDR4 4733+(OC)/4666(OC)/
4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/
4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/
3600(OC)/3466(OC)/3200/2933/2667/2400/2133*
* Lihat Daar Dukungan Memori di situs web ASRock untuk informasi
selengkapnya. (http://www.asrock.com/)
* Lihat halaman 24 untuk dukungan frekuensi maksimum DDR4
UDIMM.
•
Kapasitas maksimum memori sistem: 64GB
•
Mendukung modul memori Extreme Memory Prole (XMP)
•
15μ Bidang Kontak Berwarna Emas di Slot DIMM
Slot
Ekspansi
•
1 x Slot PCI Express 3.0 x16 (PCIE1: x16 mode)*
* Mendukung kartu riser PCIe untuk memperpanjang slot x8/x8
* Mendukung SSD NVMe sebagai disk boot
•
1 x Soket M.2 Vertikal (tombol E) dengan paket modul WiFi-
802.11ac (di bagian belakang I/O)

ASROCK A520M-ITX/ac Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 9 3rd Gen
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466 MHz
Component for	PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of HDDs supported	5
Supported storage drive interfaces	M.2, SATA III
Graphics card	Radeon Vega
Number of SATA III connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
BIOS type	UEFI AMI
Cables included	SATA
LAN controller	Realtek RTL8111H
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
