ASROCK A520M-ITX/ac Manual

82
繁體中文
BIOS 功能
•
AMI UEFI Legal BIOS 含 GUI 支援
•
支援「隨插即用」
•
ACPI 5.1 符合喚醒自動開機
•
支援免跳線模式
•
支援 SMBIOS 2.3
•
CPU、CPU VDDCR_SOC、DRAM、VPPM、+1.8VSB、
VDDP 電壓多重調整
硬體顯示器
•
溫度感應：CPU、機殼／水冷幫浦風扇
•
風扇轉速計：CPU、機殼／水冷幫浦風扇
•
靜音風扇（依 CPU 溫度自動調整機殼風扇速度）：CPU、
機殼／水冷幫浦風扇
•
風扇多重速度控制：CPU、機殼／水冷幫浦風扇
•
電壓監控：+12V、+5V、+3.3V、CPU Vcore
作業系統
•
Microso® Windows® 10 64-bit
認證
•
FCC、CE
•
ErP/EuP ready（須具備 ErP/EuP ready 電源供應器）

ASROCK A520M-ITX/ac Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 9 3rd Gen
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466 MHz
Component for	PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of HDDs supported	5
Supported storage drive interfaces	M.2, SATA III
Graphics card	Radeon Vega
Number of SATA III connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
BIOS type	UEFI AMI
Cables included	SATA
LAN controller	Realtek RTL8111H
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
