ASROCK A520M-ITX/ac Manual

78
简体中文
简体中文
BIOS 功能
特点
•
AMI UEFI Legal BIOS，支持 GUI
•
支持“即插即用”
•
ACPI 5.1 兼容唤醒事件
•
支持免跳线 (jumperfree)
•
支持 SMBIOS 2.3
•
CPU、CPU VDDCR_SOC、DRAM、VPPM、+1.8VSB、
VDDP 电压多次调整 (Voltage Multi-adjustment)
硬件监控
•
温度感测：CPU、机箱 / 水泵风扇
•
风扇转速计：CPU、机箱 / 水泵风扇
•
静音风扇（根据 CPU 温度自动调整机箱风扇速度）：CPU、
机箱 / 水泵风扇
•
风扇多种速度控制：CPU、机箱 / 水泵风扇
•
电压监控：+12V、+5V、+3.3V、CPU Vcore
操作系统
•
Microso® Windows® 10 64-bit
认证
•
FCC、CE
•
ErP/EuP 支持（需要支持 ErP/EuP 的电源）

ASROCK A520M-ITX/ac Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 9 3rd Gen
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466 MHz
Component for	PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of HDDs supported	5
Supported storage drive interfaces	M.2, SATA III
Graphics card	Radeon Vega
Number of SATA III connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
BIOS type	UEFI AMI
Cables included	SATA
LAN controller	Realtek RTL8111H
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
