1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
IDE1
SOCKET AM2
FSB800
DDRII_1 (64 bit, 240-pin module)
DDRII_2 (64 bit, 240-pin module)
FSB800
DDRII_3 (64 bit, 240-pin module)
DDRII_4 (64 bit, 240-pin module)
AMD
SB710
Chipset
PS2_USB_PW1
1
ATX12V1
CPU_FAN1
8Mb
BIOS
CMOS
BATTERY
CLRCMOS1
1
COM1
LAN
PHY
1
AUDIO
CODEC
Super
I/O
IR1
1
CD1
HD_AUDIO1
1
PCIE1
1
HDMI_SPDIF1
FLOPPY1
HDLED RESET
PLED PWRBTN
1
PANEL1
CHA_FAN1
SPEAKER1
1
USB8_9
1
USB6_7
1
SATAII_2
DDR2 1066
Dual Channel
AM2+/AM3
20.8cm (8.2-in)
30.5cm (12.0-in)
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
16
17
18
19
20
2122
2324
25
262728
29
30
31
32
33
34
35
AMD
770
Chipset
PCIE2
PCIE3
PCI1
PCI2
PCI3
A770DE+
SATAII_4
SATAII_1
SATAII_3
SATAII_5
SATAII_6
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Mouse
PS2
Keyboard
USB 2.0
T: U SB 0
B: USB1
Top:
RJ-45
Coaxial
SPDIF
Optical
SPDIF
USB 2.0
T:USB2
B: USB3
USB 2.0
T:USB4
B: USB5
140W CPU
FSB2.6GHz
PCI Express 2.0
RAID
RoHS
Phenom II
HT3.0
USB10_11
1
PWR_FAN1
36
1 PS2_USB_PW1 Jumper 19 Chassis Fan Connector (CHA_FAN1)
2 ATX 12V Power Connector (ATX12V1) 20 USB 2.0 Header (USB8_9, Blue)
3 AM2 940-Pin CPU Socket 21 USB 2.0 Header (USB6_7, Blue)
4 CPU Heatsink Retention Module 22 USB 2.0 Header (USB10_11, Blue)
5 CPU Fan Connector (CPU_FAN1) 23 System Panel Header (PANEL1, Orange)
6 2 x 240-pin DDR2 DIMM Slots 24 SPI Flash Memory (8Mb)
(Dual Channel A: DDRII_1, DDRII_2; Yellow) 25 Infrared Module Header (IR1)
7 2 x 240-pin DDR2 DIMM Slots 26 Floppy Connector (FLOPPY1)
(Dual Channel B: DDRII_3, DDRII_4; Orange) 27 Serial Port Connector (COM1)
8 ATX Power Connector (ATXPWR1) 28 Front Panel Audio Header
9 Primary IDE Connector (IDE1, Blue) (HD_AUDIO1, Lime)
10 Clear CMOS Jumper (CLRCMOS1) 29 Internal Audio Connector: CD1 (Black)
11 Southbridge Controller 30 HDMI_SPDIF Header
12 Fifth SATAII Connector (SATAII_5, Red) (HDMI_SPDIF1, Yellow)
13 Sixth SATAII Connector (SATAII_6, Red) 31 PCI Slots (PCI1- 3)
14 Primary SATAII Connector (SATAII_1, Red) 32 PCI Express 2.0 x16 Slot
15 Third SATAII Connector (SATAII_3, Red) (PCIE3; Orange)
16 Fourth SATAII Connector (SATAII_4, Red) 33 PCI Express 2.0 x16 Slot (PCIE2; Green)
17 Chassis Speaker Header 34 PCI Express x1 Slot (PCIE1; Green)
(SPEAKER 1, Purple) 35 Power Fan Connector (PWR_FAN1)
18 Secondary SATAII Connector (SATAII_2, Red) 36 Northbridge Controller
