CHB Addr/Cmd Fine Delay
Use this to adjust values for CHB Addr/Cmd Fine Delay feature. Configura-
tion options: [Auto], [No Delay], [1/64CLK] to [31/64CLK]. The default value
is [Auto].
CHB Addr/Cmd Setup Time
Use this to adjust values for CHB Addr/Cmd Setup Time feature. Configura-
tion options: [Auto], [1/2CLK] and [1CLK]. The default value is [Auto].
CHB CS/ODT Fine Delay
Use this to adjust values for CHB CS/ODT Fine Delay feature. Configuration
options: [Auto], [No Delay], [1/64CLK] to [31/64CLK]. The default value is
[Auto].
CHB CS/ODT Setup Time
Use this to adjust values for CHB CS/ODT Setup Time feature. Configura-
tion options: [Auto], [1/2CLK] and [1CLK]. The default value is [Auto].
CHA CKE Drive Strength
Use this to adjust values for CHA CKE Drive Strength. Configuration options:
[Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
CHA CS/ODT Drive Strength
Use this to adjust values for CHA CS/ODT Drive Strength. Configuration
options: [Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is
[Auto].
CHA ODDR/CMD Drive Strength
Use this to adjust values for CHA ODDR/CMD Drive Strength. Configuration
options: [Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is
[Auto].
CHA CLK Drive Strength
Use this to adjust values for CHA CLK Drive Strength. Configuration options:
[Auto], [0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA DATA Drive Strength
Use this to adjust values for CHA DATA Drive Strength. Configuration options:
[Auto], [0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA DQS Drive Strength
Use this to adjust values for CHA DQS Drive Strength. Configuration options:
[Auto], [0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA Processor ODT
Use this to adjust values for CHA Processor ODT. Configuration options:
[Auto], [240 ohms], [120 ohms] and [60 ohms]. The default value is [Auto].
CHB CKE Drive Strength
Use this to adjust values for CHB CKE Drive Strength. Configuration options:
[Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
