English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 4 x 240-pin DDR3/DDR3L DIMM Slots
(DDR3_A1, DDR3_A2, DDR3_B1, DDR3_B2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 Chassis Fan Connector (CHA_FAN3)
5 ATX Power Connector (ATXPWR1)
6 USB 3.0 Header (USB_5_6)
7 Chassis Fan Connector (CHA_FAN2)
8 SATA3 Connector (SATA3_0)
9 SATA3 Connector (SATA3_2)
10 SATA3 Connector (SATA3_1)
11 SATA3 Connector (SATA3_3)
12 SATA3 Connector (SATA3_5)
13 SATA3 Connector (SATA3_4)
14 System Panel Header (PANEL1)
15 Power LED and Speaker Header (SPK_PLED1)
16 USB 2.0 Header (USB_11_12)
17 USB 2.0 Header (USB_9_10)
18 Clear CMOS Jumper (CLRMOS1)
19 Chassis Fan Connector (CHA_FAN1)
20 TPM Header (TPMS1)
21 COM Port Header (COM1)
22 Front Panel Audio Header (HD_AUDIO1)
23 CPU Fan Connector (CPU_FAN1)
24 CPU Fan Connector (CPU_FAN2)
