Page #4 background imageLoading...
Page #4 background image
2
English
No. Description
1 Clear CMOS Jumper (CLRMOS1)
2 ATX 12V Power Connector (ATX12V1)
3 CPU Fan Connector (CPU_FAN1)
4 Chassis Fan Connector (CHA_FAN2)
5 2 x 240-pin DDR3/DDR3L DIMM Slots (DDR3_A1, DDR3_B1)
6 2 x 240-pin DDR3/DDR3L DIMM Slots (DDR3_A2, DDR3_B2)
7 ATX Power Connector (ATXPWR1)
8 USB 3.0 Header (USB_11_12)
9 SATA3 Connector (SATA3_4)
10 SATA3 Connector (SATA3_5)
11 SATA3 Connectors (SATA3_0_2)
12 SATA3 Connectors (SATA3_1_3)
13 SATA Express Connector (SATA_E_1_2)
14 Chassis Intrusion and Speaker Header (SPK_CI1)
15 System Panel Header (PANEL1)
16 USB 2.0 Header (USB_9_10)
17 USB 2.0 Header (USB_7_8)
18 Print Port Header (LPT1)
19 COM Port Header (COM1)
20 COM Port Header (COM2)
21 TPM Header (TPMS1)
22 Front Panel Audio Header (HD_AUDIO1)
23 Chassis Fan Connector (CHA_FAN1)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B150M Pro4/D3 and is the answer not in the manual?

ASROCK B150M Pro4/D3 Specifications

General IconGeneral
Audio chipRealtek ALC892
Certification- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)
Component forPC
Motherboard chipsetIntelĀ® B150
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10 x64, Windows 7, Windows 7 x64, Windows 8.1 x64
Processor socketLGA 1151 (Socket H4)
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds1066, 1333, 1600, 1866 MHz
BIOS typeUEFI AMI
ACPI version5.0
BIOS memory size128 Mbit
System Management BIOS (SMBIOS) version2.7
PS/2 ports quantity2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Wi-FiNo
LAN controllerIntel I219V
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Number of SATA III connectors6
Parallel processing technology supportCrossFireX, Quad-GPU CrossFireX
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSATA III
Weight and Dimensions IconWeight and Dimensions
Width244 mm
