ASROCK B365M-ITX/ac User Manual

3
English
B365M-ITX/ac
I/O Panel
No. Description No. Description
1 PS/2 Mouse/Keyboard Port 7 USB 3.1 Gen1 Ports (USB3_3_4)
2 LAN RJ-45 Port* 8 USB 3.1 Gen1 Ports (USB3_1_2)
3 Line In (Light Blue)** 9 DisplayPort 1.2 (DISPLAY1)
4 Front Speaker (Lime)** 10 DVI-I Port (DVI1)
5 Microphone (Pink)** 11 HDMI Port (HDMI1)
6 Antenna Ports
* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
11
5
7
8
10
2
1
9
4
3
6
