Step 4
Move the stando based on the
module type and length.
e stando is placed at the nut
location A by default. Skip Step 4
and 5 and go straight to Step 6 if you
are going to use the default nut.
Otherwise, release the stando by
hand.
AB
Step 5
Peel o the yellow protective lm on
the nut to be used. Hand tighten the
stando into the desired nut location
on the motherboard.
B
A
B
A
20
o
Step 6
Gently insert the M.2 (NGFF) SSD
module into the M.2 slot. Please
be aware that the M.2 (NGFF) SSD
module only ts in one orientation.
NUT1NUT2
Step 7
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw
as this might damage the module.
