ASROCK B550M-C R2.0 User Manual

English
3
B550M-C R2.0
* For Ryzen Series APUs (Picasso, Cezanne and Renoir), ECC
is only supported with PRO CPUs.
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 23 for AMD non-XMP memory
frequency support. For more details, please refer to the QVL
on ASRock's website.
•
Max. capacity of system memory: 128GB
•
Supports Extreme Memory Prole (XMP) memory
modules
Expansion
Slot
AMD Ryzen series CPUs (Vermeer and Matisse)
•
2 x PCI Express x16 Slots (PCIE1: Gen4x16 mode; PCIE4:
Gen3 x4 mode)*
AMD Ryzen series APUs (Cezanne and Renoir)
•
2 x PCI Express x16 Slots (PCIE1: Gen3x16 mode; PCIE4:
Gen3 x4 mode)*
AMD Ryzen series APUs (Picasso)
•
2 x PCI Express x16 Slots (PCIE1: Gen3x8 mode; PCIE4:
Gen3 x4 mode)*
* Supports NVMe SSD as boot disks
•
Supports AMD CrossFire
TM
•
2 x PCI Express 3.0 x16 Slots (PCIE2/PCIE3: x1 mode)
•
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/
BT PCIe WiFi module
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU* (Actual support may vary by CPU)
•
1 x HDMI 2.1, supports HDR, HDCP 2.3, 4K Ultra HD
(UHD) playback and max. resolution up to 4K 60Hz*
* Picasso supports HDCP 2.2 with HDMI 2.0 Port
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111H

ASROCK B550M-C R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD B550
Socket	AM4
Max Memory	128GB
Memory Speed	DDR4 4733+(OC)
PCIe x16 Slots	1
USB 3.2 Gen1 (Rear)	4
USB 2.0 (Rear)	2
USB 3.2 Gen1 (Front)	2
USB 2.0 (Front)	2
RAID Support	RAID 0, 1, 10
Memory Slots	4
PCIe x1 Slots	1
Storage Interface	6 x SATA3
M.2 Slots	1
LAN	Realtek RTL8111H
Audio	7.1 CH HD Audio (Realtek ALC897 Audio Codec)
