ASROCK B560 PRO4 - Page 32

24
English
RGB LED Headers
(4-pin RGB_LED1)
(see p.7, No. 29)
(4-pin RGB_LED2)
(see p.7, No. 7)
12V GRB
1
12V
G
R
B
1
RGB headers are used to connect
RGB LED extension cables which
allow users to choose from
various LED lighting eects.
Caution: Never install the
RGB LED cable in the wrong
orientation; otherwise, the cable
may be damaged.
*Please refer to page 46 for further
instructions on this header.
Addressable LED Headers
(3-pin ADDR_LED1)
(see p.7, No. 28)
(3-pin ADDR_LED2)
(see p.7, No.6)
VOUT
DO_ADDR
GND
1
ese headers are used to connect
Addressable LED extension cables
which allow users to choose from
various LED lighting
eects.
Caution: Never install the Ad-
dressable LED cable in the wrong
orientation; otherwise, the cable
may be damaged.
*Please refer to page 47 for
further instructions on this
header.
