No. Description
1 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
4 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
5 CPU Fan Connector (CPU_FAN1)
6 Addressable LED Header (ADDR_LED1)
7 RGB LED Header (RGB_LED1)
8 ATX Power Connector (ATXPWR1)
9 USB 3.2 Gen1 Header (USB3_5_6)
10 Front Panel Type C USB 3.2 Gen2x2 Header (F_USB3_TC_1)
11 SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_3) (Lower)
12 SATA3 Connector (SATA3_4) (Upper), SATA3 Connector (SATA3_5) (Lower)
13 System Panel Header (PANEL1)
14 SATA3 Connector (SATA3_1)
15 SATA3 Connector (SATA3_0)
16 SPI TPM Header (SPI_TPM_J1)
17 POST Status Checker (PSC)
18 USB 2.0 Header (USB5_6)
19 USB 2.0 Header (USB3_4)
20 Chassis Intrusion and Speaker Header (SPK_CI1)
21 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
22 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
23 Clear CMOS Jumper (CLRMOS1)
24 RGB LED Header (RGB_LED2)
25 Addressable LED Header (ADDR_LED2)
26 Front Panel Audio Header (HD_AUDIO1)
27 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
