USB 2.0 Headers
(9-pin USB_5_6) (see p.6, No. 21)
(9-pin USB_7_8) (see p.6, No. 22)
ere are two headers on this motherboard. Each USB 2.0 header can support two
ports.
B6 50 M- CX
DUMMY
GND
GND
P+
P-
USB_PWR
P+
P-
USB_PWR
1
USB_7_8
DUMMY
GND
GND
P+
P-
USB_PWR
P+
P-
USB_PWR
1
USB_5_6
