ASROCK B660 PRO RS Manual

English
7
B660 Pro RS
** Supports Intel® Optane
TM
Technology (M2_3 only)
** Supports Intel® Volume Management Device (VMD)
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
RAID
•
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Connector
•
1 x COM Port Header
•
1 x SPI TPM Header
•
1 x Chassis Intrusion and Speaker Header
•
1 x RGB LED Header
* Supports in total up to 12V/3A, 36W LED Strip
•
3 x Addressable LED Headers
* Support in total up to 5V/3A, 15W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* e CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
•
5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP and CHA_FAN1~5/WP can auto detect if
3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector
•
1 x underbolt AIC Connector (5-pin) (Supports ASRock
underbolt 4 AIC Card)
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports
ESD Protection)
•
2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
(Supports ESD Protection)
•
1 x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD
Protection)

ASROCK B660 PRO RS Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B660
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Cables included	SATA
Drivers included	Yes
DisplayPort version	1.4
DVI-D ports quantity	0
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Wi-Fi	No
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
Number of M.2 (M) slots	3
Maximum resolution	7680 x 4320 pixels
Parallel processing technology support	-
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4800 MHz
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
