English
37
B760 TW/D4 V2
ATX 12V Power Connector
(4-pin ATX12V2) (see p.6, No. 2)
Please connect an ATX 12V power supply to this connector.
*e power supply plug ts into this connector in only one orientation.
*Connecting an ATX 12V 4-pin cable to ATX12V2 is optional.
*For advanced overclocking we suggest using this connector together with
ATX12V1.
