English
7
B760M-C
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
3 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
4 CPU Fan Connector (CPU_FAN1)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 Addressable LED Header (ADDR_LED3)
7 Addressable LED Header (ADDR_LED2)
8 ATX Power Connector (ATXPWR1)
9 SATA3 Connectors (SATA3_A3)(Upper), (SATA3_A4)(Lower)
10 USB 3.2 Gen1 Header (USB32_4_5)
11 Front Panel Type C USB 3.2 Gen1 Header (USB32_TC2)
12 SATA3 Connectors (SATA3_A1)(Upper), (SATA3_A2)(Lower)
13 System Panel Header (PANEL1)
14 SATA3 Connector (SATA3_0)
15 SATA3 Connector (SATA3_1)
16 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
17 SPI TPM Header (SPI_TPM_J1)
18 Post Status Checker (PSC)
19 SATA3 Connector (SATA3_2)
20 SATA3 Connector (SATA3_3)
21 USB 2.0 Header (USB_7_8)
22 USB 2.0 Header (USB_5_6)
23 Chassis Intrusion and Speaker Header (SPK_CI1)
24 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
25 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
26 Addressable LED Header (ADDR_LED1)
27 Clear CMOS Jumper (CLRMOS1)
28 RGB LED Header (RGB_LED1)
29 Front Panel Audio Header (HD_AUDIO1)
30 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
