USB 2.0 Header
(9-pin USB_5_6) (see p.6, No. 18)
ere is one header on this motherboard. is USB 2.0 header can support two
ports.
USB 3.2 Gen1 Header
(19-pin USB3_5_6) (see p.6, No. 10)
ere is one header on this motherboard. is USB 3.2 Gen1 header can support
two ports.
USB_5_6
DUMMY
G ND
G ND
+B
-B
USB_PWR
+A
-A
USB_PWR
1
1
IntA _P B_ D+
Dumm y
IntA _P B_ D-
GND
IntA _P B_ SSTX+
GND
IntA _P B_ SSTX-
IntA _P B_ SSRX+
IntA _P B_ SSRX-
VbusVbus
Vbus
IntA_PA_SSRX-
IntA_PA_SSRX+
GND
IntA_PA_SSTX-
IntA_PA_SSTX+
GND
IntA_PA_D-
IntA_PA_D+
USB3_5_6
