B85M Pro3
7
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
4 ATX Power Connector (ATXPWR1)
5 USB 3.0 Header (USB3_2_3)
6 SATA3 Connector (SATA_1)
7 SATA3 Connector (SATA_0)
8 SATA3 Connector (SATA_2)
9 SATA3 Connector (SATA_3)
10 Chassis Speaker Header (SPEAKER1)
11 System Panel Header (PANEL1)
12 Chassis Fan Connector (CHA_FAN1)
13 SATA2 Connector (SATA_4)
14 SATA2 Connector (SATA_5)
15 Chassis Intrusion Header (CI1)
16 USB 2.0 Header (USB6_7)
17 USB 2.0 Header (USB4_5)
18 TPM Header (TPMS1)
19 Front Panel Audio Header (HD_AUDIO1)
20 CPU Fan Connector (CPU_FAN1)
21 Clear CMOS Jumper (CLRCMOS1)
