Fatal1ty AB350 Gaming-ITX/ac Series
55
Italiano
I/O pannello
posteriore
•
2 x porte antenna
•
1 x porta mouse/tastiera PS/2
•
2 x porte HDMI
•
1 x porta uscita SPDIF ottico
•
2 x porte USB 2.0 (supporta protezione da scariche elettrostat-
iche)
* È inclusa 1 porta mouse Fatal1ty (USB 2.0)
•
1 x Porta USB 3.0 di tipo A (supporta protezione da scariche
elettrostatiche)
•
1 x Porta USB 3.0 di tipo C (supporta protezione da scariche
elettrostatiche)
•
2 x porte USB 3.0 (supporta protezione da scariche elettrostat-
iche)
•
1 x porta LAN RJ-45 con LED (ACT/LINK LED e SPEED
LED)
•
Connettori audio HD: altoparlante posteriore/centrale/basso/
ingresso linea/altoparlante anteriore/microfono (connettori
audio dorati)
Archiviazione
•
4 x connettori SATA3 6,0 Gb/s, supporto RAID (RAID 0, RAID
1, e RAID 10), NCQ, AHCI e Hot Plug
•
1 x socket Ultra M.2, supporta il modulo M.2 SATA3 6,0 Gb/s
di tipo M Key 2280 ed il modulo M.2 PCI Express no a Gen3
x4 (32 Gb/s) (con Ryzen CPU) o Gen3 x2 (16 Gb/s) (con APU
serie A)*
* Supporto di SSD NVMe come disco davvio
* Supporta kit ASRock U.2
Connettore
•
1 x connettore LPC
•
1 x Collettore LED AMD FAN
•
1 x connettore ventola CPU (4-pin)
* Il connettore ventola CPU supporta ventole CPU con potenza
massima di 1 A (12 W).
•
1 x Connettore ventola telaio (4-pin)
•
1 x connettore ventola telaio optional/ventola pompa dellacqua
(4 pin) (Smart Fan Speed Control)
* La ventola telaio/ventola pompa dellacqua supporta ventole di
sistemi di rareddamento ad acqua di potenza massima di 1,5A
(18W).
* CHA_FAN1/W_PUMP sono in grado di rilevare se è in uso una
ventola a 3 pin o 4 a pin.
•
1 x connettore alimentazione ATX 24 pin
•
1 x connettore alimentazione 12V 8-pin (connettore
alimentazione ad alta densità)
•
1 x connettore audio pannello frontale
•
1 x collettore USB AMD LED FAN
