ASROCK Fatal1ty AB350 Gaming-ITX/ac Series User Manual

1
English
Fatal1ty AB350 Gaming-ITX/ac Series
Motherboard Layout
BIOS
ROM
ATXPWR1
CLR CMO S1
1
1
USB _3_ 4
HD_ AUD IO 1
1
CPU _FA N1
RJ-45 LAN
SOCKET AM4
HDMI2
ATX1 2V 1
Ultra M.2
PCIe Gen3 x4
USB3 _3_4
1
CHA _FA N2
HDLE D RE SET
PLED P WRB TN
PANE L1
1
RoHS
DDR4_A1 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin modul e)
AMD
Promontory
B350
U SB 3.0
T: USB1
B : USB2
AMD _FAN _LE D1
1
LPC 1
1
AB350 Gaming-ITX/ac
PCIE1
CHA _FA N/ W_P UM P
USB 3. 0
T: US B31 _TA _1
B: USB 31 _TC _1
USB 2.0
T: USB1
B: USB2
PS2
Keyb oar d
/Mou se
HDMI1
Top:
Central/Bass
Cent er:
REAR SP K
Top:
LINE IN
Cent er:
FRON T
Bott om:
Opti cal
SPDI F
Bott om:
MIC I N
USB _5
1
SPE AKE R1
1
M2_WIFI_1
SATA3 _2
SATA3 _4
SATA3 _1
SATA3 _3

ASROCK Fatal1ty AB350 Gaming-ITX/ac Series Specifications

General

Form Factor	Mini-ITX
Chipset	AMD B350
CPU Socket	AM4
Maximum Memory	32GB
PCIe Slots	1 x PCIe 3.0 x16
Audio	7.1 CH HD Audio (Realtek ALC1220 Audio Codec)
RAID Support	RAID 0, 1, 10
HDMI	1 x HDMI
DisplayPort	1 x DisplayPort
Memory Slots	2 x DIMM
Memory Speed	DDR4 3200+(OC)
Storage Interface	4 x SATA3, 1 x Ultra M.2
Network	Gigabit LAN 10/100/1000 Mb/s
Bluetooth	Bluetooth 4.2
USB Ports	2 x USB 2.0, 6 x USB 3.1 Gen1
