ASROCK Fatal1ty AB350 Gaming-ITX/ac Series User Manual

English
2
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 AMD LED Fan USB Header (USB_5)
3 AMD Fan LED Header (AMD_FAN_LED1)
4 CPU Fan Connector (CPU_FAN1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6 Chassis Fan Connector (CHA_FAN2)
7 ATX Power Connector (ATXPWR1)
8 USB 2.0 Header (USB_3_4)
9 USB 3.0 Header (USB3_3_4)
10 SATA3 Connector (SATA3_2)
11 SATA3 Connector (SATA3_1)
12 SATA3 Connector (SATA3_3)
13 SATA3 Connector (SATA3_4)
14 System Panel Header (PANEL1)
15 LPC Header (LPC1)
16 Clear CMOS Jumper (CLRCMOS1)
17 Chassis Fan / Waterpump Fan Connector (CHA_FAN/W_PUMP)
18 Front Panel Audio Header (HD_AUDIO1)
19 Chassis Speaker Header (SPEAKER1)

ASROCK Fatal1ty AB350 Gaming-ITX/ac Series Specifications

General

Form Factor	Mini-ITX
Chipset	AMD B350
CPU Socket	AM4
Maximum Memory	32GB
PCIe Slots	1 x PCIe 3.0 x16
Audio	7.1 CH HD Audio (Realtek ALC1220 Audio Codec)
RAID Support	RAID 0, 1, 10
HDMI	1 x HDMI
DisplayPort	1 x DisplayPort
Memory Slots	2 x DIMM
Memory Speed	DDR4 3200+(OC)
Storage Interface	4 x SATA3, 1 x Ultra M.2
Network	Gigabit LAN 10/100/1000 Mb/s
Bluetooth	Bluetooth 4.2
USB Ports	2 x USB 2.0, 6 x USB 3.1 Gen1
