ASROCK Fatal1ty FM2A88X Plus Killer User Manual

PB
1
English
Fatal1ty FM2A88X+ Killer Series
Motherboard Layout
Super
I/O
CMOS
BATTERY
ATXPWR1
PCIE1
PCI1
CPU_FAN1
64Mb
BIOS
PCIE2
CPU_FAN2
FM2A88X+ Killer
PCIE4
DDR3_A1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
PWR_FAN1
CHA_FAN3
PCIE3
PCI2
PCI3
1
CLRCMOS1
HDLED RESET
PLED PWRBTN
1
PANEL1
SATA3 _1_2SATA3 _3_4SATA3 _5_6SATA3_7_ 8
CHA_FAN1
CHA_FAN2
SPEAKER1
1
PLED1
1
HD_AUDIO1
1
COM1
1
1
USB_7_8
1
USB_9_10
Top:
CTR BA SS
Cent er:
REAR S PK
Bott om:
Opti cal
SPDI F
Top:
LINE I N
Cent er:
FRON T
Bott om:
MIC IN
Top:
RJ-45
VGA1
DVI1
USB 3.0
T: USB1
B: USB2
HDMI1
Clr
CMOS
USB 3.0
T: USB3
B: USB4
USB 2.0
T: USB3
B: USB4
USB3_5 _6
RoHS
SOCKET FM2b
AMD
A88X
(Bolton-D4)
Chipset
USB 2.0
T: USB1
B: USB2
PS2
Keyboard/
Mouse
1
USB_5_6
TPMS1
1
CI1
1
2
3
4
5
1
6
7
8
11
10
12
14
16
18
20
172125
22
2326
19
27
ATX 12V1
13
SLI/XFIRE_PWR1
24
Killer
E2200
Purity
Sound
TM
FATALTY1
9
15

ASROCK Fatal1ty FM2A88X Plus Killer Specifications

General

Socket	FM2+
Chipset	AMD A88X
Max Memory	64GB
PCI Express 3.0 x16	1
PCI Express 2.0 x16	1
PCI Express x1	2
PCI Slots	2
SATA 6Gb/s	8
Audio Chipset	Realtek ALC1150
Audio Channels	7.1
Max. LAN Speed	10/100/1000Mbps
Form Factor	ATX
Memory Support	DDR3 2400+(OC)/2133/1866/1600/1333
SATA RAID	0, 1, 5, 10
LAN Chipset	Qualcomm Atheros Killer E2200
Video Ports	HDMI, DVI-D, D-Sub
USB 2.0 Ports	8 (4 front, 4 rear)
Memory Slots	4 x DIMM
USB 3.0 Ports	6 (2 front, 4 rear)
