ASROCK Fatal1ty Z77 Professional-M series User Manual

8
1.2 Specifications
Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
- Premium Gold Capacitor design (100% Japan-made
high-quality Conductive Polymer Capacitors)
CPU - Supports 3
rd
and 2
nd
Generation Intel
®
Core
TM
i7 / i5 / i3 in
LGA1155 Package
- Digi Power Design
- 8 + 3 Power Phase Design
- Supports Intel
®
Turbo Boost 2.0 Technology
- Supports Intel
®
K-Series unlocked CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
- Supports Intel
®
Rapid Start Technology and Smart Connect
Technology with Intel
®
Ivy Bridge CPU
Chipset - Intel
®
Z77
Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)
- 4 x DDR3 DIMM slots
- Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/
1600/1333/1066 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB (see CAUTION 3)
- Supports Intel
®
Extreme Memory Prole (XMP)1.3/1.2
Expansion Slot - 2 x PCI Express 3.0 x16 slots (PCIE1/PCIE3: single at x16
(PCIE1) / x8 (PCIE3) or dual at x8/x8 mode)
(see CAUTION 4)
* PCIE 3.0 is only supported with Intel
®
Ivy Bridge CPU. With
Intel
®
Sandy Bridge CPU, it only supports PCIE 2.0.
- 1 x PCI Express 2.0 x16 slot (PCIE4: x4 mode)
- 1 x PCI Express 2.0 x 1 slot
- Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and
CrossFireX
TM
- Supports NVIDIA
®
Quad SLI
TM
and SLI
TM
Graphics * Intel
®
HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
- Supports Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick
Sync Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000,
Intel
®
Advanced Vector Extensions (AVX)
- Pixel Shader 5.0, DirectX 11 with Intel
®
Ivy Bridge CPU.
Pixel Shader 4.1, DirectX 10.1 with Intel
®
Sandy Bridge
CPU.

ASROCK Fatal1ty Z77 Professional-M series Specifications

General

Chipset	Intel Z77
CPU Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
PCI Slots	1
Audio Chipset	Realtek ALC898
LAN Chipset	Broadcom BCM57781
Max. LAN Speed	10/100/1000Mbps
Form Factor	Micro ATX
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
PCI Express x16	2 x PCI Express 3.0 x16
PCI Express x1	1 x PCI Express 2.0 x1
SATA 6Gb/s	4 x SATA 6Gb/s
SATA 3Gb/s	4 x SATA 3Gb/s
USB 3.0	4 (2 rear, 2 via header)
USB 2.0	8 x USB 2.0 ports (4 on the rear panel, 4 via headers)
Audio	7.1 Channel HD Audio
LAN	Gigabit LAN
Dimensions	9.6" x 9.6"
Power Pin	24 Pin
Onboard Video Chipset	Depends on CPU (Intel HD Graphics)
Multi-GPU Support	NVIDIA SLI, AMD CrossFireX
