ASROCK FM2A88M Extreme4+ R2.0 User Manual

8
1.4 I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB_3_4)* 8 Microphone (Pink)
2 D-Sub Port 9 Optical SPDIF Out Port
3 LAN RJ-45 Port** 10 USB 2.0 Ports (USB_1_2)*
4 Central / Bass (Orange) 11
USB 3.0 Ports (USB3_1_2)
(AMD A88X (Bolton-D4))
5 Rear Speaker (Black) 12 HDMI Port
6 Line In (Light Blue) 13 DVI-D Port
7 Front Speaker (Lime)*** 14 PS/2 Mouse/Keyboard Port
1 2 3 5
891011121314
4
7
6
