ASROCK FM2A88M Extreme4+ R2.0 User Manual

2
1.2 Specications
Platform - Micro ATX Form Factor
- All Solid Capacitor design
- High Density Glass Fabric PCB
CPU - Supports Socket FM2+ 95W / FM2 100W processors
- 4 + 2 Power Phase design
Chipset - AMD A88X (Bolton-D4)
Memory - Dual Channel DDR3 Memory Technology
- 4 x DDR3 DIMM Slots
- Supports DDR3 2400+(OC)/2133/1866/1600/1333/1066
non-ECC, un-buffered memory (see CAUTION 1)
- Max. capacity of system memory: 64GB (see CAUTION 2)
- Supports Intel
®
ExtremeMemoryProle(XMP)1.3/1.2
 -SupportsAMDMemoryProleTechnology(AMP)uptoAMP
2400
Expansion Slot - 1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode)
* PCIE 3.0 is only supported with FM2+ CPU. With FM2
CPU, it only supports PCIE 2.0.
- 1 x PCI Express 2.0 x16 Slot (PCIE3 @ x4 mode)
- 1 x PCI Express 2.0 x1 Slot
- 1 x PCI Slot
- Supports AMD Quad CrossFireX
TM
, CrossFireX
TM
and Dual
Graphics
Graphics - Integrated AMD Radeon
TM
R7/R5 Series Graphics in
A-series APU
- DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX 11,
Pixel Shader 5.0 with FM2 CPU.
- Max. shared memory 2GB
 -Threegraphicsoutputoptions:D-Sub,DVI-DandHDMI
Ports
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K × 2K
(4096x2160) @ 24Hz
* Only FM2+ APU can support up to 4096x2160 resolution
display via HDMI port
 -SupportsDual-linkDVI-Dwithmax.resolutionupto
2560x1600 @ 60Hz
- Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
