Front Panel
Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio Front
Panel.
OnBoard Lan
This allows you to enable or disable the “OnBoard Lan” feature.
DRAM Voltage
Use this to select DRAM Voltage. Configuration options: [Auto], [1.794V],
[1.851V], [1.908V], [1.965V], [2.029V], [2.086V], [2.144V] and [2.201V].
The default value of this feature is [Auto].
NB Voltage
Use this to select NB Voltage. Configuration options: [Auto], [1.272V] and
[1.319V]. The default value of this feature is [Auto].
VTT Voltage
Use this to select VTT Voltage. Configuration options: [Auto], [1.10V],
[1.20V], [1.37V] and [1.46V]. The default value of this feature is [Auto].
+1.5V Voltage
Use this to select +1.5V Voltage. Configuration options: [Auto], [1.5125V]
and [1.5651V]. The default value of this feature is [Auto].
Intelligent Energy Saver
Intelligent Energy Saver is a revolutionary technology that delivers
unparalleled power savings. The default value is [Auto]. Configuration
options: [Auto], [Enabled] and [Disabled]. If you want to enable this function,
please set this item to [Enabled]. Besides the BIOS option, you can also
choose our Intelligent Energy Saver utility to enable this function.
DRAM RCOMP Setting
Use this to adjust DRAM RCOMP Setting feature. Configuration options:
[Auto] and [Manual]. The default value of this feature is [Auto].
