H110TM-ITX
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Front Speaker / Microphone
Storage
•
2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and
Hot Plug
•
1 x mSATA Connector, support NCQ, AHCI and Hot Plug
* MINI_SATA1: RST utility port0; SATA3_0: RST utility port2;
SATA3_1: RST utility port3
Connector
•
1 x CIR Header
•
2 x COM Port Headers
•
1 x TPM Header
•
1 x SPDIF Out Connector
•
1 x Monitor Switch Header
•
1 x Backlight Power Jumper
•
1 x Panel Power Jumper
•
1 x Backlight & Amp Volume Control Header
•
1 x LVDS Connector
•
1 x Home eater PC Header
•
1 x CPU Fan Connector (4-pin)
•
1 x Chassis Fan Connector (4-pin) (Smart Fan Speed
Control)
* CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x Front Panel Audio Connector
•
1 x Analog Surround Audio Header
•
1 x Digital MIC Header
•
1 x 3W Audio AMP Output Wafer Header
•
1 x Internal Power Header
•
1 x SATA Power Connector
•
3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
* USB3_4_5 is shared with USB4_5.
