ASROCK H61M-VS R2.0 User Manual

45
3.4.5 Super IO Configuration
Serial Port
Use this item to enable or disable the onboard serial port.
Serial Port Address
Use this item to set the address for the onboard serial port. Confi guration
options: [3F8 / IRQ4] and [3E8 / IRQ4].
Parallel Port
Use this item to enable or disable the onboard parallel port.
Device Mode
Use this item to change the Printer Port mode.
Change Settings
Use this item to select an optional setting for Super IO device.

ASROCK H61M-VS R2.0 Specifications

General

Chipset	Intel H61
CPU Socket	LGA 1155
Maximum Memory	16GB
Storage Interface	4 x SATA 3Gb/s
LAN	Realtek RTL8111E Gigabit LAN
Form Factor	Micro ATX
Video Outputs	1 x D-Sub
Power Connector	24-pin ATX, 4-pin ATX 12V
Memory Slots	2 x DIMM
Memory Standard	DDR3 1600/1333/1066
Expansion Slots	1 x PCIe 2.0 x1
USB Ports	8 x USB 2.0
Audio	Realtek ALC662 5.1-Channel HD Audio
