ASROCK H67M Brochure & Specs

Intel
®
H67 Chipset
H67M
www.asrock.com
100% All Solid
Capacitor design
C.C.O.C.C.O.
Combo Cooler Option
C.C.O. provides the flexible option to adopt three
different CPU cooler types, Socket LGA 775*,
LGA 1155 and LGA 1156**
*C.C.O. may not be compatible with all Socket 775 CPU coolers.
**O is for Socket 1155 and Socket 1156 CPU cooler.
Support Intel
®
K-Series unlocked CPU

ASROCK H67M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Number of memory slots	2
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
USB 2.0 connectors	3
Number of COM connectors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
Headphone outputs	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC892
Certification	FCC, CE, WHQL, ErP/EuP Ready
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP 32/64-bit
Graphics card	-
Maximum graphics card memory	1759 MB
Parallel processing technology support	Not supported
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mb/s
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	218 mm
Width	244 mm
