Page #6 background image
2
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
All Solid Capacitor design
•
High Density Glass Fabric PCB
CPU
•
Supports New 4
th
and 4
th
Generation Intel® Core
TM
i7/i5/i3/
Xeon®/Pentiu/Celeron® Processors (Socket 1150)
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H81
Memory
•
Dual Channel DDR3 Memory Technology
•
2 x DDR3 DIMM Slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB
(see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP)1.3/1.2
Expansion
Slot
•
1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)
•
1 x PCI Express 2.0 x1 Slot
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 4400/4600
•
Pixel Shader 5.0, DirectX 11.1
•
Max. shared memory 1792MB
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
Audio
•
5.1 CH HD Audio (Realtek ALC662 Audio Codec)
•
Supports Surge Protection (ASRock Full Spike Protection)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H81M-VG4 R2.0 and is the answer not in the manual?

ASROCK H81M-VG4 R2.0 Specifications

General IconGeneral
ECCNo
Memory channelsDual-channel
Memory slots typeDIMM
Unbuffered memoryYes
Number of memory slots2
Supported memory typesDDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
Processor socketLGA 1150 (Socket H3)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 seriesi3-4xxx, i5-4xxx, i7-4xxx
Maximum number of SMP processors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Supported storage drive interfacesSATA II, SATA III
USB 2.0 ports quantity4
LAN controllerRealtek RTL8111GR
Ethernet interface typeGigabit Ethernet
Audio chipRealtek ALC662
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP ready
Component forPC
Power source typeATX
Motherboard chipsetIntel® H81
PC health monitoringCPU, FAN, Temperature, Voltage
Audio output channels5.1 channels
Motherboard form factormicro ATX
Parallel processing technology supportNot supported
BIOS typeUEFI AMI
ACPI version1.1
BIOS memory size32 Mbit
Cables includedSATA
Weight and Dimensions IconWeight and Dimensions
Width- mm
