ASROCK H81M-VG4 R3.0 User Manual

40
简体中文
规格
平台
• Micro ATX 规格尺寸
• CPU 供电电路固态电容
CPU
• 支持新款第 4 代和第 4 代 Intel® Core
TM
i7/i5/i3/Xeon®/
Pentium®/Celeron® 处理器 (Socket 1150)
• 支持 Intel® Turbo Boost 2.0 技术
芯片集
• Intel® H81
内存
• 双通道 DDR3 内存技术
• 2 x DDR3 DIMM 槽
• 支持 DDR3 1600/1333/1066 非 ECC，非缓冲内存
• 支持系统内存容量： 16GB
• 支持 Intel® Extreme Memory Prole (XMP)1.3/1.2
扩充槽
• 1 x PCI Express 2.0 x16 槽 (PCIE2: x16 模式 )
• 1 x PCI Express 2.0 x1 槽
图形
• 只有 GPU 集成的处理器才支持 Intel® HD Graphics 内置视
效和 VGA 输出。
• 支持 Intel® HD Graphics 内置视效 : Intel® 快速同步视频，采
用 AVC、MVC (S3D) 和 MPEG-2 Full HW Encode1、Intel®
InTru
TM
3D、Intel® Clear Video HD 技术、Intel® Insider
TM
、
Intel® HD Graphics 4400/4600
• Pixel Shader 5.0、DirectX 11.1
• 最大共享内存 1024MB
• 支持 D-Sub，60Hz 时最大分辨率达 1920x1200
音频
• 7.1 声道高保真音频 (Realtek ALC887 音频编码解码器 )
* 要配置 7.1 CH 高清音频，需要使用高清前面板模块和通过音
频驱动程序启用多通道音频功能。
• 支持防突波 ( 华擎全防护 )

ASROCK H81M-VG4 R3.0 Specifications

General

Non-ECC	Yes
Internal memory	16 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600 MHz
Certification	FCC, CE, WHQL, ErP/EuP ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Processor socket	LGA 1150 (Socket H3)
Compatible processor series	Intel Celeron, Intel Pentium
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit
Maximum resolution	1920 x 1080 pixels
LAN controller	Realtek RTL8111C
Ethernet interface type	Gigabit Ethernet
PCI Express x1 (Gen 2.x) slots	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
Bundled software	- ASRock Disk Health Report - ASRock USB Key - ASRock APP Charger - ASRock XFast LAN - ASRock XFast RAM - ASRock Fast Boot (Fast Boot, Restart to UEFI) - ASRock Interactive UEFI - ASRock UEFI Guide - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS - ASRock UEFI Tech Service - ASRock Easy Driver Installer
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	- mm
