ASROCK H81M-VG4 R3.0 User Manual

41
简体中文
H81M-VG4 R3.0
LAN
• PCIE x1 千兆网卡 10/100/1000 Mb/s
• Realtek RTL8111C
• 支持网络喚醒功能 (Wake-On-LAN)
• 支持防雷擊 / 防 ESD 靜電（ASRock 全防護）
• 支持網路線偵測功能
• 支持 PXE
后面板 I/O
• 1 個 PS/2 鼠標接口
• 1 個 PS/2 鍵盤接口
• 1 x D-Sub 端口
• 2 x USB 2.0 端口 （支持防 ESD 静电 ( 华擎全防护 )
• 2 x USB 3.0 端口 （支持防 ESD 静电 ( 华擎全防护 )
• 1 x RJ-45 LAN 端口，带 LED（ACT/LINK LED 和 SPEED
LED）
• 高清音频插孔 : 线路输入 / 前扬声器 / 麦克风
存储
• 2 x SATA3 6.0 Gb/s 接口，支持 NCQ、AHCI 和“热插拔”
功能
• 2 x SATA2 3.0 Gb/s 接口，支持 NCQ、AHCI 和“热插拔”
功能
接口
• 1 x 机箱侵入接脚
• 1 x TPM 接脚
• 1 x CPU 风扇接口 (4 针 )
• 1 x 机箱风扇接口 (4 针 )
• 1 x 24 针 ATX 电源接口
• 1 x 4 针 12V 电源接口
• 1 x 前面板音频接口
• 2 x USB 2.0 接脚（支持 4 个 USB 2.0 端口）（支持防 ESD 静
电 ( 华擎全防护 )
BIOS 功能特点
• AMI UEFI Legal BIOS，具有多语言 GUI 支持
• ACPI 1.1 兼容唤醒事件
• SMBIOS 2.3.1 支持
• CPU、DRAM 电压多次调整（Voltage Multi-adjustment）

ASROCK H81M-VG4 R3.0 Specifications

General

Non-ECC	Yes
Internal memory	16 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600 MHz
Certification	FCC, CE, WHQL, ErP/EuP ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Processor socket	LGA 1150 (Socket H3)
Compatible processor series	Intel Celeron, Intel Pentium
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit
Maximum resolution	1920 x 1080 pixels
LAN controller	Realtek RTL8111C
Ethernet interface type	Gigabit Ethernet
PCI Express x1 (Gen 2.x) slots	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
Bundled software	- ASRock Disk Health Report - ASRock USB Key - ASRock APP Charger - ASRock XFast LAN - ASRock XFast RAM - ASRock Fast Boot (Fast Boot, Restart to UEFI) - ASRock Interactive UEFI - ASRock UEFI Guide - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS - ASRock UEFI Tech Service - ASRock Easy Driver Installer
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	- mm
