1 Pendahuluan
Terima kasih telah membeli motherboard ASRock H81M, yakni motherboard
andal yang diproduksi di bawah kendali mutu ketat yang sejalan dengan ASRock.
Motherboard ini memberikan performa luar biasa dengan desain canggih yang
meneguhkan komitmen ASRock terhadap kualitas dan ketahanan.
1.1 Isi Kemasan
• Motherboard ASRock H81M (Bentuk dan Ukuran Micro ATX)
• Panduan Ringkas ASRock H81M
• CD Dukungan ASRock H81M
• 2 x Kabel Data SATA (Serial ATA) (Opsional)
• 1 x Pelindung Panel I/O
Karena spesikasi motherboard dan perangkat lunak BIOS dapat di-update, maka
isi dokumentasi ini akan berubah sewaktu-waktu tanpa pemberitahuan sebelumnya.
Jika terdapat perubahan pada dokumentasi ini, maka versi baru akan tersedia di situs
web ASRock tanpa pemberitahuan lebih lanjut. Jika Anda memerlukan dukungan
teknis terkait motherboard ini, kunjungi situs web kami untuk mendapatkan
informasi khusus tentang model yang Anda gunakan. Anda juga dapat menemukan
kartu VGA dan daar dukungan CPU terkini di situs web ASRock. Situs web ASRock
http://www.asrock.com.

ASROCK H81M Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-4xxx, i5-4xxx, i7-4xxx
Power fan connector	Yes
Number of SATA connectors	-
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
PC health monitoring	CPU, FAN, Power supply, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Supported storage drive interfaces	SATA II, SATA III
DirectX version	11.1
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1792 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
LAN controller	Atheros AR8171
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit

Weight and Dimensions

Width	- mm
