ASROCK H81M Manual

H81M
151
Bahasa Indonesia
1.2 Spesikasi
Platform
• Bentuk dan Ukuran Micro ATX
• Desain Kapasitor Solid
CPU
• Mendukung Intel® Core
TM
i7 / i5 / i3 Generasi Ke-4 / Xeon® /
Pentium® / Celeron® dalam Paket LGA1150
• Desain 4 Fase Daya
• Mendukung Teknologi Intel® Turbo Boost 2.0
Chipset
• Intel® H81
Memori
• Teknologi Memori DDR3 Kanal Ganda
• 2 x Slot DDR3 DIMM
• Mendukung DDR3 1600/1333/1066 non-ECC, memori tanpa
buer
• Kapasitas maksimum memori sistem: 16GB
(lihat PERHATIAN)
• Mendukung Intel® Extreme Memory Prole (XMP)1.3/1.2
Slot Ekspansi
• 2 x Slot PCI Express 2.0 x16 (PCIE1: x16 mode; PCIE2: x4
mode)
• 2 x Slot PCI
• Mendukung AMD Quad CrossFireX
TM
dan CrossFireX
TM
Gras
• Intel® HD Graphics Built-in Visuals dan output VGA hanya
didukung dengan prosesor yang terintegrasi GPU.
• Mendukung Intel® HD Graphics Built-in Visuals: Intel® Quick
Sync Video dengan AVC, MVC (S3D), dan MPEG-2 Full HW
Encode1, Intel® InTru
TM
3D, Teknologi Intel® Clear Video HD,
Intel® Insider
TM
, Intel® HD Graphics 4600
• Pixel Shader 5.0, DirectX 11.1
• Memori bersama maksimum 1792MB
• Tiga pilihan output VGA: D-Sub, DVI-D, dan HDMI
• Mendukung Teknologi HDMI dengan resolusi maksimum
hingga 1920x1200 @ 60Hz
• Mendukung DVI-D dengan resolusi maksimum hingga
1920x1200 @ 60Hz

ASROCK H81M Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-4xxx, i5-4xxx, i7-4xxx
Power fan connector	Yes
Number of SATA connectors	-
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
PC health monitoring	CPU, FAN, Power supply, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Supported storage drive interfaces	SATA II, SATA III
DirectX version	11.1
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1792 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
LAN controller	Atheros AR8171
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit

Weight and Dimensions

Width	- mm
