Page #9 background imageLoading...
Page #9 background image
H81M
7
English
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required)
•
Supports HDCP function with DVI-D and HDMI ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
•
Premium Blu-ray audio support
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Qualcomm® Atheros® AR8171
•
Supports Qualcomm® Atheros® Security Wake On Internet
Technology
•
Supports Wake-On-LAN
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Keyboard Port
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
1 x Optical SPDIF Out Port
•
4 x USB 2.0 Ports
•
2 x USB 3.0 Ports
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front
Speaker / Microphone

Other manuals for ASROCK H81M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H81M and is the answer not in the manual?

ASROCK H81M Specifications

General IconGeneral
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
Processor socketLGA 1150 (Socket H3)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 seriesi3-4xxx, i5-4xxx, i7-4xxx
Power fan connectorYes
Number of SATA connectors-
Number of Parallel ATA connectors0
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Audio chipRealtek ALC892
Cooling typePassive
Component forPC
Power source typeATX
Motherboard chipsetIntel® H81
PC health monitoringCPU, FAN, Power supply, Temperature
Audio output channels7.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Supported storage drive interfacesSATA II, SATA III
DirectX version11.1
Maximum resolution1920 x 1200 pixels
Maximum graphics card memory1792 MB
Parallel processing technology support2-Way CrossFireX, Quad-GPU CrossFireX
LAN controllerAtheros AR8171
Ethernet interface typeGigabit Ethernet
BIOS typeUEFI AMI
ACPI version1.1
BIOS memory size32 Mbit
Weight and Dimensions IconWeight and Dimensions
Width- mm
