ASROCK H97M User Manual

4
English
•
4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Storage
•
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
13 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug
Connector
•
1 x Print Port Header
•
1 x COM Port Header
•
1 x Chassis Intrusion Header
•
1 x TPM Header
•
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
•
2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
•
1 x Power Fan Connector (3-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
1 x SPDIF Out Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
BIOS
Feature
•
64Mb AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 1.1 Compliant wake up events
•
SMBIOS 2.3.1 support
•
DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment
Support
CD
•
Drivers, Utilities, AntiVirus Soware (Trial Version), Google
Chrome Browser and Toolbar, Start8 (30 days trial), Kloudian
Orbweb.ME Professional (Win 8.1 / 7)

ASROCK H97M Specifications

General

Form Factor	Micro ATX
Chipset	Intel H97
Socket	LGA 1150
Maximum Memory	32GB
PCI Express 3.0 x16	1
PCI Express x1	2
SATA 6Gb/s	6
SATA Express	1
M.2	1
Audio Chipset	Realtek ALC892
Audio Channels	7.1
Max LAN Speed	10/100/1000Mbps
Memory Slots	4
PCI Express 2.0 x16	1
Video Ports	DVI-D, HDMI
USB 3.0 Ports	2 x Front
USB 2.0 Ports	4 x Front
