ASROCK H97M User Manual

2
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
All Solid Capacitor design
•
High Density Glass Fabric PCB
Unique
Feature
ASRock Full Spike Protection
ASRock Cloud
ASRock APP Shop
CPU
•
Supports 4
th
Gen & 5
th
Generation Intel® Core
th
Processors
(Socket 1150)
•
4 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H97
Memory
•
Dual Channel DDR3 Memory Technology
•
2 x DDR3 DIMM Slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB (see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
•
1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
•
2 x PCI Slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 4400/4600
•
Pixel Shader 5.0, DirectX 11.1
•
Max. shared memory 1792MB
•
ree graphics output options: D-Sub, DVI-D and HDMI

ASROCK H97M Specifications

General

Form Factor	Micro ATX
Chipset	Intel H97
Socket	LGA 1150
Maximum Memory	32GB
PCI Express 3.0 x16	1
PCI Express x1	2
SATA 6Gb/s	6
SATA Express	1
M.2	1
Audio Chipset	Realtek ALC892
Audio Channels	7.1
Max LAN Speed	10/100/1000Mbps
Memory Slots	4
PCI Express 2.0 x16	1
Video Ports	DVI-D, HDMI
USB 3.0 Ports	2 x Front
USB 2.0 Ports	4 x Front
