ASROCK H97M User Manual

H97M
3
English
•
Supports Triple Monitor
•
Supports HDMI with max. resolution up to 1920x1200 @
60Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
•
Supports HDCP with DVI-D and HDMI Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI Ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection (ASRock Full Spike Protection)
•
ELNA Audio Caps
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Qualcomm® Atheros® AR8171
•
Supports Qualcomm® Atheros® Security Wake On Internet
Technology
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
1 x Optical SPDIF Out Port
•
4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))

ASROCK H97M Specifications

General

Form Factor	Micro ATX
Chipset	Intel H97
Socket	LGA 1150
Maximum Memory	32GB
PCI Express 3.0 x16	1
PCI Express x1	2
SATA 6Gb/s	6
SATA Express	1
M.2	1
Audio Chipset	Realtek ALC892
Audio Channels	7.1
Max LAN Speed	10/100/1000Mbps
Memory Slots	4
PCI Express 2.0 x16	1
Video Ports	DVI-D, HDMI
USB 3.0 Ports	2 x Front
USB 2.0 Ports	4 x Front
