ASROCK PHANTOM GAMING B650E PG-ITX WiFi User Manual

English
48
Step 3
Before installing a M.2 SSD
module, please loosen the screws to
remove Blazing M.2 Gen5 Fan
Heatsink.
*Please remove the protective lms
on the bottom side of Blazing M.2
Gen5 Fan Heatsink before you
install a M.2 SSD module.
Step 4
Align and gently insert the M.2 SSD
module into the M.2 slot. Please
be aware that the M.2 SSD module
only ts in one orientation.
A
A
20
o
2
1
1

ASROCK PHANTOM GAMING B650E PG-ITX WiFi Specifications

General

Chipset	AMD B650E
Form Factor	Mini-ITX
Memory Slots	2 x DIMM
Max Memory	64GB
PCIe Slots	1 x PCIe 5.0 x16
Bluetooth	Bluetooth 5.2
Ethernet	2.5 Gigabit LAN
CPU Socket Type	AM5
Memory Speed	DDR5 6400+(OC)
Storage Interface	4 x SATA3
Wireless	Wi-Fi 6E
USB Ports	1 x USB 3.2 Gen2x2 Type-C
Video Outputs	1 x HDMI, 1 x DisplayPort
