Z790 Riptide WiFi
Step 3
Align and gently insert the M.2 SSD
card into the M.2 slot. Please be
aware that the M.2 SSD card only ts
in one orientation.
Step 4
Ensure that the notch at the end of
the M.2 SSD card aligns with the
nut. en secure the M.2 SSD card
by turning the nut lock clockwise to
its locked position.
Step 5
Hook the tab of the M.2 heatsink
back onto the stando.
20
