2.2 Expansion Slots (PCI Express Slots)
ere is 1 PCI Express slot and 1 mini PCI Express slot on this motherboard.
PCIe slot:
PCIE1 (PCIe 2.0 x4 slot) is used for PCI Express x4 lane width cards.
mini-PCIe slot:
MINI_PCIE1 (mini-PCIe slot) is used for WiFi module.
Before installing an expansion card, please make sure that the power supply is switched o
or the power cord is unplugged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.
