English
8
AMD Ryzen series CPUs (Picasso)
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*
* Supports PCIe riser cards to extend one x16 slot to two x8 slots
if you install AMD Ryzen series CPUs
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ax module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Supports HDMI 2.0 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports DisplayPort 1.4 Input with max. resolution up to
4K x 2K (4096x2160) @ 120Hz
* DisplayPort 1.4 Input is used to connect a Type-C Monitor.
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant
HDMI monitor is required)
•
Supports HDR (High Dynamic Range) with HDMI 2.0
•
Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.4
Ports
•
Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and
DisplayPort 1.4 Ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek
ALC1220 Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection
•
Nichicon Fine Gold Series Audio Caps
•
Pure Power-In
•
Direct Drive Technology
•
PCB Isolate Shielding
