ASROCK X570 Phantom Gaming-ITX/TB3 Manual

47
X570 Phantom Gaming-ITX/TB3
Français
1.2 Spécications
Plateforme
•
Facteur de forme Mini-ITX
•
PCB cuivre 2 onces
Processeur
•
Prend en charge la gamme de processeurs AMD AM4 socket
Ryzen™ 2000 et 3000
•
Digi Power design
•
Alimentation à 10 phases
Chipset
•
AMD X570
Mémoire
•
Technologie mémoire double canal DDR4
•
2 x fentes DIMM DDR4
•
Les processeurs AMD série Ryzen (Matisse) prennent en
charge les mémoires sans tampon ECC et non ECC DDR4
4533+(OC)/4400(OC)/4300(OC)/4266(OC)/4200(OC)/
4133(OC)/3466 (OC)/3200/2933/2667/2400/2133*
•
Les processeurs AMD série Ryzen (Pinnacle Ridge) prennent
en charge les mémoires sans tampon* ECC et non ECC DDR4
3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133
•
Les processeurs AMD série Ryzen (Picasso) prennent en
charge les mémoires sans tampon non ECC DDR4
3466+ (OC)/3200(OC)/2933/2667/2400/2133*
* Sur les processeurs série Ryzen (Picasso), ECC est pris en charge
uniquement avec les processeurs PRO.
* Veuillez consulter la liste de prise en charge des mémoires sur le
site Web d'ASRock pour de plus amples informations.
(http://www.asrock.com/)
* Veuillez consulter la page 19 pour connaître la prise en charge
de la fréquence maximale de l'UDIMM DDR4.
•
Capacité max. de la mémoire système : 64Gb
•
Contacts dorés 15μ sur fentes DIMM
Fente
d’expansion
Processeurs AMD série Ryzen (Matisse)
•
1 x fente PCI Express 4.0 x 16 (PCIE1:mode x16)*
Processeurs AMD série Ryzen (Pinnacle Ridge)
•
1 x fente PCI Express 3.0 x 16 (PCIE1:mode x16)*

ASROCK X570 Phantom Gaming-ITX/TB3 Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
ECC	Yes
Memory voltage	1.2 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 4133, 4200, 4266, 4300, 4400, 4533 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	Not supported
Number of SATA III connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Headphone outputs	3
USB connector type	USB Type-A, USB Type-C
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	256 Mbit
LAN controller	Intel® I211-AT
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC1220
Cooling type	Passive
Certification	FCC, CE, ErP/EuP ready
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Windows operating systems supported	Windows 10
Supported processor sockets (cooler)	LGA 115x
UEFI version	2.3.0
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
