X570 Phantom Gaming-ITX/TB3
2.3 Installing Memory Modules (DIMM)
is motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots,
and supports Dual Channel Memory Technology.
AMD non-XMP Memory Frequency Support
Ryzen Series CPUs (Matisse):
Ryzen Series CPUs (Pinnacle Ridge):
1. For dual channel conguration, you always need to install identical (the same
brand, speed, size and chip-type) DDR4 DIMM pairs.
2. It is unable to activate Dual Channel Memory Technology with only one memory
module installed.
3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.
UDIMM Memory Slot
# of DIMMs on
the Channel
# of Ranks
per DIMM
1.20V
1 of 1 xR 3200
1 of 2 xR-0 2933-3200
2 of 2 1R-1R 2667
2 of 2 2R-xR 2400-2667
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2933
- SR 2933
DR - 2933
- DR 2933
SR SR 2933
DR DR 2933
