1.2 Specications
Platform
•
Mini-ITX Form Factor
•
2oz Copper PCB
CPU
•
Supports AMD AM4 socket Ryzen™ 2000 and 3000 series
processors
•
Digi Power design
•
10 Power Phase design
Chipset
•
AMD X570
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
AMD Ryzen series CPUs (Matisse) support DDR4 4533+
(OC)/4400(OC)/4300(OC)/4266(OC)/4200(OC)/4133
(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-
ECC, un-buered memory*
•
AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4
3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133 ECC
& non-ECC, un-buered memory*
•
AMD Ryzen series CPUs (Picasso) support DDR4 3466+
(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buered
memory*
* For Ryzen Series CPUs (Picasso), ECC is only supported with
PRO CPUs.
* Please refer to Memory Support List on ASRocks website for
more information. (http://www.asrock.com/)
* Please refer to page 19 for DDR4 UDIMM maximum
frequency support.
•
Max. capacity of system memory: 32GB
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
AMD Ryzen series CPUs (Matisse)
•
1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode)*
AMD Ryzen series CPUs (Pinnacle Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
