ASROCK X570S PG Riptide - Page 11

English
5
X570S PG Riptide
Storage
•
6 x SATA3 6.0 Gb/s Connectors
•
1 x Hyper M.2 Socket (M2_1), supports M Key type
2230/2242/2260/2280 M.2 PCI Express module up to
Gen4x4 (64 Gb/s) (with Vermeer, Matisse) or Gen3x4
(32 Gb/s) (with Renoir, Pinnacle Ridge and Picasso)*
•
1 x Hyper M.2 Socket (M2_2), supports M Key type
2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2
PCI Express module up to Gen4x4 (64 Gb/s)*
* If M2_2 is occupied by a PCIE-type M.2 device, SATA3_5_6
will be disabled.
* If underbolt support is enabled, SATA type M.2 will be
disabled.
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
RAID
•
Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices
•
Supports RAID 0 and RAID 1 for M.2 NVMe storage
devices
Connector
•
1 x Power LED and Speaker Header
•
2 x RGB LED Headers
* Support in total up to 12V/3A, 36W LED Strip
•
2 x Addressable LED Headers
* Support in total up to 5V/3A, 15W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* e CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
•
5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP, CHA_
FAN3/WP, CHA_FAN4/WP and CHA_FAN5/WP can auto
detect if 3-pin or 4-pin fan is in use.
